• Standard access control board functionality supports direct connection to card readers.
• All functional components are pre-wired internally at the factory; the gate only requires connection of bridging cables, Ethernet cables, and power cables for operation.
• Supports advanced features including single-lane anti-passback, multi-lane cross-controller anti-passback, and multi-factor verification.
• Enables quick setup via the web interface.
• Supports external Bluetooth speakers for playing gate audio.
• Incorporates an advanced non-destructive transmission mechanism paired with high-quality DC brushless motors, ensuring precise control, stable operation, and extended lifetime.
• Utilizes cutting-edge motor control technology with a closed-loop control system and DSP-based self-regulating motor control, combined with proprietary motor control algorithms for precise positioning and stable performance of the blocking mechanism.
• Comprehensive safety design.
• Implements dual smart anti-pinch protection through advanced infrared sensors and current detection, ensuring complete pedestrian safety.
• All electrical modules operate on safe voltages below 24V, preventing electric shock hazards.
• Motors are installed in the under section of the gate, effectively preventing water damage from rain exposure.
• Supports automatic door opening during power failure for efficient crowd evacuation.
• Features a built-in professional receiver module, supporting 1-to-32 door opening configurations (remote transmitter modules must be purchased separately).
• Allows flexible selection of normal passage modes: keep open or keep closed. Effectively alleviates crowd pressure by adjusting door wing speed based on pedestrian flow, improving operational efficiency.
• Comprehensive infrared functionality:
• 16 pairs of infrared sensors effectively monitor passage status.
• Accurately detects reverse passing, tailgating, and other unauthorized intrusions, triggering audible and visual alarms.
• Alarms can be transmitted via serial port to backend management systems for integration with related systems.
• Door wings utilize clamp installation for easy disassembly and maintenance.
• Equipped with self-diagnostic functionality to provide prompt alerts for abnormalities, facilitating user maintenance and operation.
• Other features
• Supports networked operation and maintenance, meeting specifications for fault diagnosis, event management, access mode configuration, and core mechanism control.
• Detects the number of people by infrared sensors, uploads data to the platform for statistics, records the number of events such as tailgating, reverse passing, and illegal intrusion, and reports alarms.
