| Model | NVR301-04Z3-P4 | NVR301-08Z3-P8 | NVR301-16Z3-P8 |
| Decoding | |||
| Decoding Format | Ultra 265, H.265, H.264 | ||
| Decoding Capability | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080P@30, 8 x 720P@30, 16 x D1@25 |
| Decoding Capability Description | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width | |
| Audio Compression | G.711A, G.711U | ||
| Network | |||
| Incoming Bandwidth | 64 Mbps | ||
| Outgoing Bandwidth | 48 Mbps | ||
| Remote Users | 128 | ||
| Protocols | TCP/IP|P2P|UPnP|NTP|DHCP|PPPoE|HTTP|HTTPS|DNS|DDNS|SMTP|RTSP|IPv4 | TCP/IP|P2P|UPnP|NTP|DHCP|PPPoE|HTTP|HTTPS|DNS|DDNS|SMTP|RTSP|IPv4 | TCP/IP|P2P|UPnP|NTP|DHCP|PPPoE|HTTP|HTTPS|DNS|DDNS|SMTP|RTSP |
| Browser (Plugin) | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ | Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above) |
| Video/Audio Input | |||
| IP Video Input | 4-ch | 8-ch | 16-ch |
| Video/Audio Output | |||
| HDMI Output | 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | HDMI:4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA Output | 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | VGA:1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| RCA Audio Output | 1-ch | ||
| Liveview Display | 1/4 | 1/4/6/8/9 | 1/4/6/8/9/16 |
| Corridor Mode Screen | 3/4 | 3/4/5/7/9 | 3/4/5/7/9/10/12/16 |
| Snapshot | |||
| FTP/Schedule/Event Snapshot | 1-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution) | 1-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution) | 1-ch snapshot, up to D1 resolution |
| Recording | |||
| Recording Resolution | 8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF | ||
| Synchronous Playback in Local | 4-ch | 8-ch | 16-ch |
| Smart | |||
| VCA Detection by IPC | Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD) | ||
| VCA Search | Face Snapshot Search, Behavior Search | ||
| Smart by IPC | Total 4-ch(Face Detection, SIP, UMD) | ||
| Alarm | |||
| General Alarm | Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection | ||
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | ||
| GUI Language | |||
| GUI Language | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian | |
| Hard Disk | |||
| SATA | 1 SATA Interface | ||
| Capacity | Up to 10 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size) | Up to 10 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size) | Up to 10 TB for each HDD (The maximum HDD capacity varies with environment temperature) |
| External Interface | |||
| Network Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet Interface | ||
| USB | Rear panel: 2 × USB2.0 | ||
| RS485 | N/A | ||
| RS232 | N/A | ||
| Alarm In | N/A | ||
| Alarm Out | N/A | ||
| Power Supply | DC 48 V/1.35 A | DC 52 V/1.8 A | DC 52 V/1.8 A |
| PoE | |||
| PoE Interface | 4 RJ45 10 M/100 M self-adaptive Ethernet Interface | 8 RJ45 10 M/100 M self-adaptive Ethernet Interface | 8 RJ45 10 M/100 M self-adaptive Ethernet Interface |
| Max Power | Max 30 W for single port, Max 54 W in total | Max 30 W for single port, Max 75 W in total | Max 30 W for single port, Max 75 W in total |
| Supported Standard | IEEE 802.3at, IEEE 802.3af | ||
| Working Environment | |||
| Working Temperature | -10 ℃ to 55 ℃ (14 ℉ to 131 ℉) | ||
| Working Humidity | ≤ 90% RH (non-condensing) | ||
| Power Consumption (without HDD) | ≤ 9W | ||
| Dimensions | |||
| Weight (without HDD) | ≤ 1.1Kg (2.43lb) | ||
| Dimensions | 260mm × 240mm × 46mm (10.2"×9.4"×1.8") | ||
| Certification | |||
| Certification | CE; FCC; UL; RoHS; WEEE | ||
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 | ||
| FCC | Part15 Subpart B | ||
