UAC-T132-F28 | UAC-T132-F40 | |||||||
Sensor | ||||||||
Pixel | 2 MP | |||||||
Sensor Size | 1/3.2" CMOS | |||||||
Min. Illumination | 0.02 lux (F2.0, AGC ON) 0 lux (IR on) | |||||||
Lens | ||||||||
Focus | 2.8 mm | 4.0 mm | ||||||
Lens Mount | M12 | |||||||
Angle of View (H) | 99.7° | 87.7° | ||||||
Angle of View (V) | 55.1° | 47.6° | ||||||
Angle of View (D) | 117.1° | 106.9° | ||||||
Illuminator | ||||||||
Illuminator Number | One IR illuminator | |||||||
Illumination Distance | 20m | |||||||
Lifetime | ≥60000 hours | |||||||
Video | ||||||||
Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) | |||||||
Frame Rate | TVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps AHD: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps CVI: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC | |||||||
Shutter Time | PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s | |||||||
Image | ||||||||
Exposure Mode | Four modes: Global(default), BLC, HLC, DWDR | |||||||
Day/Night | Three modes: Auto (default), Day, Night | |||||||
Digital Noise Reduction | 2D/3D | |||||||
White Balance | Two modes: Auto (default), Manual | |||||||
WDR | DWDR | |||||||
Smart IR | Support | |||||||
Flip | Supports 180°horizontal flip, 180°vertical flip | |||||||
Digital Defog | N/A | |||||||
Audio | ||||||||
Built-in Mic | N/A | |||||||
Camera Audio | N/A | |||||||
Interface | ||||||||
Power Interface | 5.5 mm Power Interface | |||||||
Video Output | BNC, supports TVI/AHD/CVI/CVBS | |||||||
Operating Environment | ||||||||
Temperature | -20 °C ~ 60 °C (-4 °F ~ 140 °F) | |||||||
Humidity | ≤95% RH (non-condensing) | |||||||
Surge Protection | 4kV for power&4kV for video output interfaces | |||||||
Ingress Protection | N/A | |||||||
General | ||||||||
Power | DC12V±25% | |||||||
Power Consumption | MAX 1.9W | |||||||
Dimensions | Φ85mm*72mm (diameter*height) | |||||||
Material | Plastic | |||||||
Weight | 89.3g(0.20lb) |
Class | Date | Title | Language | Type | Download |
Datasheet | 11/28/2024 6:46:42 PM | UNV UAC-T132-F28(40) 2MP Fixed IR Turret Analog Camera.pdf | English | Download |
Class | Date | Title | Type | Download |
HD Image | 10/22/2024 9:33:56 AM | UAC-T132-F28_HD_Image_1.png | png | Download |
HD Image | 10/22/2024 9:33:56 AM | UAC-T132-F28_HD_Image_2.png | png | Download |
HD Image | 10/22/2024 9:33:56 AM | UAC-T132-F28_HD_Image_3.png | png | Download |
Class | Date | Title | Language | Type | Download |
User Manual | 2024/11/7 20:53:48 | UNV-Analog Cameras User Manual.pdf | English | Download |
Class | Date | Title | Language | Type | Download |
Quick Guide | 8/21/2024 5:23:32 AM | Quick Guide.pdf | English | Download |
Class | Date | Title | Download |
Dimensions | 10/22/2024 9:33:56 AM | UAC-T132-F28_Dimensions_1.png | Download |
Title | Language | Type | Download |
GUAC-B2601.1.7.231107-ALL.zip | English | zip | Download |
