| | PWR-300A-IN |
| AC Input |
| Voltage | 90~264V AC |
| Frequency | 47~63Hz |
| Power Factor | ≥0.95 |
| Input Current | ≤4A@100VAC |
| Input Protection | Input undervoltage, Input overvoltage |
| DC Output |
| Voltage/Current | +12VDC/25A, +12VStandby/0.7A |
| Output Power | 312W |
| Output Efficiency | ≥83%, 220V AC/25A |
| Line Regulation | ±5% |
| Load Regulation | ±3% |
| Regulated Voltage Accuracy | ±5% |
| Dynamic Response Overshoot | ±5% |
| Current Sharing Rate | ±5% |
| Output Protection | Short Circuit Protection, Overload Protection, Overvoltage Protection, Hot Plug Protection, Over Temperature Protection |
| Other |
| Indicator light | Normal: green on, Abnormal: Yellow on |
| Working Temperature | 0~55℃ |
| Storage Temperature | -40~70℃ |
| Working Humidity | 10%~90% |
| Heat dissipation | Ventilating fan design, heat emission at back |
| Dimension (D × H × W) | 234.9mm×40.13mm×101.6mm |
| Certification |
| EMC standards | EN55022, EN55024 |
| NEBS standards | GR-63-CORE ISSUE 2 |
| Approved standards | CB, FCC, UL |
