UAC-T124-AF28LM | UAC-T124-AF40LM | |||||||
Sensor | ||||||||
Pixel | 4 MP | |||||||
Sensor Size | 1/3.0" CMOS | |||||||
Min. Illumination | 0.005 lux (F1.6, AGC ON) 0 lux (IR on) | |||||||
Lens | ||||||||
Focus | 2.8 mm | 4.0 mm | ||||||
Lens Mount | M12 | |||||||
Angle of View (H) | 97.7° | 81.1° | ||||||
Angle of View (V) | 54.9° | 41.0° | ||||||
Angle of View (D) | 111.9° | 94.4° | ||||||
Illuminator | ||||||||
Illuminator Number | Two IR illuminators | |||||||
Illumination Distance | 40m | |||||||
Lifetime | ≥ 60000 hours | |||||||
Video | ||||||||
Resolution | 4MP: 2560 (H) × 1440 (V) 1080P: 1920 (H) × 1080 (V) | |||||||
Frame Rate | TVI: 4MP@25fps (default), 4MP@30fps,1080P@25fps, 1080P@30fps AHD: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVI: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVBS: PAL, NTSC | |||||||
Shutter Time | PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s | |||||||
Image | ||||||||
Exposure Mode | Four modes: Global (default), BLC, HLC, DWDR | |||||||
Day/Night | Three modes: Auto (default), Day, Night | |||||||
Digital Noise Reduction | 2D | |||||||
White Balance | Two modes: Auto (default), Manual | |||||||
WDR | DWDR | |||||||
Smart IR | Support | |||||||
Flip | Supports 180°horizontal flip, 180°vertical flip | |||||||
Digital Defog | N/A | |||||||
Audio | ||||||||
Built-in Mic | Support | |||||||
Camera Audio | TVI: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVI: 4MP@25fps, 4MP@30fps | |||||||
Interface | ||||||||
Power Interface | 5.5 mm Power Interface | |||||||
Video Output | BNC, supports TVI/AHD/CVI/CVBS | |||||||
Operating Environment | ||||||||
Temperature | -30°C to 60°C (-22°F to 140°F) | |||||||
Humidity | ≤ 95% RH (non-condensing) | |||||||
Surge Protection | 4 KV for power, 4 KV for video output interfaces | |||||||
Ingress Protection | IP67 | |||||||
General | ||||||||
Power | DC 12 V ± 25% | |||||||
Power Consumption | MAX 3.5W | |||||||
Mount | Wall Mount, Pole Mount, Corner Mount, Pendant Mount | |||||||
Dimensions | Φ111mm*98mm (diameter*height) | |||||||
Material | Graphene + Metal + Plastic | |||||||
Weight | 334g(0.74lb) |
