| NVR301-04S3-P4 | NVR301-08S3-P8 | NVR301-16S3-P8 |
Decoding |
Decoding Format | Ultra 265, H.265, H.264 |
Decoding Capability | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080P@30, 8 x 720P@30, 16 x D1@25 |
Decoding Capability Description | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width | The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width |
Audio Compression | G.711A, G.711U |
Network |
Incoming Bandwidth | 64Mbps |
Outgoing Bandwidth | 48Mbps |
Remote Users | 128 |
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4 | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP, IPv4 | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP |
Browser(Plugin) | Windows: IE (IE10/ 11), Firefox (version 52.0 and above), Chrome (version 45 and above), Edge (version 79 and above) | Windows: IE (IE10/ 11), Firefox (version 52.0 and above), Chrome (version 45 and above), Edge (version 79 and above) | Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above) |
Video/Audio Input |
IP Video Input | 4-ch | 8-ch | 16-ch |
Video/Audio Output |
HDMI Output | 4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | 4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | HDMI:4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
VGA Output | 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | VGA:1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
RCA Audio Output | 1-ch |
Liveview Display | 1/4 | 1/4/6/8/9 | 1/4/6/8/9/16 |
Corridor Mode Screen | 3/4 | 3/4/5/7/9 | 3/4/5/7/9/10/12/16 |
Snapshot |
FTP/Schedule/Event Snapshot | 1-ch snapshot, up to D1 resolution |
Recording |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
Synchronous Playback in Local | 4-ch | 8-ch | 16-ch |
Smart |
VCA Detection by IPC | Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD) |
VCA Search | Behavior Search |
Smart by IPC | Total 4-ch(Face Detection, SIP, UMD) |
Alarm |
General Alarm | Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
GUI Language |
GUI Language | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian |
Hard Disk |
SATA | 1 SATA Interface |
Capacity | Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature and hard disk size) | Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature and hard disk size) | Up to 10TB for each HDD (The maximum HDD capacity varies with environment temperature) |
External Interface |
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
USB | Rear panel: 2 x USB2.0 |
RS485 | N/A |
RS232 | N/A |
Alarm In | N/A |
Alarm Out | N/A |
Power Supply | DC 48V/1.35A | DC 52V/1.8A | DC 52V/1.8A |
PoE |
PoE Interface | 4 RJ45 10M/100M self-adaptive Ethernet Interface | 8 RJ45 10M/100M self-adaptive Ethernet Interface | 8 RJ45 10M/100M self-adaptive Ethernet Interface |
Max Power | Max 30W for single port, Max 54W in total | Max 30W for single port, Max 75W in total | Max 30W for single port, Max 75W in total |
Supported Standard | IEEE 802.3at, IEEE 802.3af |
Working Environment |
Working Temperature | -10 °C ~ 55 °C (14 °F ~ 131 °F) |
Working Humidity | ≤ 90% RH (non-condensing) |
Power Consumption (without HDD) | ≤ 9W |
Dimensions |
Weight (without HDD) | ≤ 1.1Kg (2.43lb) |
Dimensions | 260mm × 240mm × 46mm (10.2"×9.4"×1.8") |
Certification |
Certification | CE; FCC; UL; RoHS; WEEE |
CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
FCC | Part15 Subpart B |
