NSW1010-8T-IN
8-Port 100 Megabit Plastic Shell Switch
• Supports IEEE802.3 and IEEE802.3u standards.
• Supports 10/100Mbps or 10/100/1000Mbps self-adaptive Ethernet port.
• Supports auto MDI/MDIX.
• Supports IEEE802.3 flow control for full-duplex mode and backpressure for half-duplex mode.
Specification
Download
How to buy
 NSW1010-8T-IN
Hardware Specification
Ports Type8 x 10/100Mbps port (RJ45)
Network Media10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m)
100Base-TX: Cat5 or higher UTP/STP (≤100m)
Switching capacity1.6 Gbps
Forwarding performance1.19Mpps
MAC2K
Jumbo Frame15K
Transfer ModeStore-and-forward
Dimensions (W×D×H)Product:
145*60*21.5mm
Packaging:
146*88*50mm
Carton InformationCarton dimensions:
530*475*315mm
Carton quantity: 100PCS
Carton weight: 17.6kg
WeightProduct: 0.111kg
Packaging: 0.166kg
Power SupplyAdapter input voltage: AC 100V to 240V
Switch input voltage: 5V, 1A
Mount MethodDesktop mount, wall mount
Cooling Fans0
Operating temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Operating humidity10%～90% (non-condensing)
Storage Temperature -20°C to 70°C
Storage Humidity 5% to 90% RH, noncondensing
IndicatorPOWER Steady on: AC input is normal, POWER Off: No AC input, LINK/ACT Off: No link, LINK/ACT Flashing: Transmitting data, LINK/ACT Steady on: Linked
